Acrel AKH-0.66K-Φ Split Core Current Transformer For Cable

Name: AKH-0.66K-Φ Split Core Current Transformer For Cable
Brand: Jiangsu Acrel Micro-grid Research & Development Institute

AKH-0.66K-Φ split core current transformers for cable are mainly used in industrial mid-city power grids and rural power grid renovation projects. They are easy to install, and do not need to disassemble the busbar of the primary side. They can also be operated with power on, without affecting the normal power consumption of customers,which can save manpower and material resources, financial resources and increase the efficiency. This series of current transformers can be used in conjunction with relay protection, measurement and metering devices.

Specification of AKH-0.66K-Φ Split Core Current Transformer For Cable

Main Parameter

Type	Ratio（A)	Burdern(VA)
Type	Ratio（A)	Class 0.2	Class 0.5	Class 1.0
K-Φ24	150/5			1
	200/5			1
	250/5		1.5
	300/5		1.5
K-Φ36	300/5		1.5
	400/5		1.5
	500/5		2.5
	600/5		2.5

Features of AKH-0.66K-Φ Split Core Current Transformer For Cable

It can be used in conjunction with the AMC16 multi-circuit monitoring instrument for the transformation of the power distribution system of 100A and below in the communication room;

It has beautiful appearance, convenient installation and wiring;

It is specially used for transformation, and there's no need to remove cables for live installation, and it is economical.
